| LCD |
Type |
23.6" Wide Color TFT LCD (Panel Type – VA panel ) |
| Display Area |
23.6 inch |
| Optimum Resolution |
1920x1080 |
| Contrast Ratio |
3000 :1 |
| Brightness |
250 cd/m2 (typ) |
| Viewing Angles |
178° / 178° (typ) |
| Response Time |
5.5ms?G delta? |
| Panel Surface |
Glare type, Hardness 3H |
| Light Source |
40,000 Hrs (Min) |
| Colors |
16.7M |
| Video Input |
Analog |
RGB Analog (75 ohms, 0.7 / 1.0 Vp-p) |
| Digital |
DVI-D (TMDS, 100ohms) |
| Frequency |
Fh: 24-82KHz; Fv: 50-60Hz |
| Sync |
Separate Sync |
| Compatibility |
PC |
VGA up to 1920x1080 Non Interlaced |
| Mac |
Power Mac up to 1920x1080 |
| Ergonomics |
Tilt |
20° ~ -5° |
| Connector |
Analog |
VGA x1 (DB-15) |
| Digital |
DVI x1 |
| Power |
Internal Power Board , 3-pin plug (CEE22) x1 |
| Power |
Voltage |
AC 100-240V (Universal); 50/60 Hz |
| Consumption |
22W (typ); Optimize:17W (typ); Conserve:13W (typ) |
| Operating Conditions |
Temperature |
32°F to 104°F (0°C to 40°C) |
| Humidity |
10% to 90% (no condensation) |
| Dimensions |
Physical |
563.89mm (width) x 407.19mm (height) x 193.14mm (depth) |
| Weight |
Net |
4.1 kg |
| Regulations |
|
CE, CB, RoHS, TCO 6.0, Erp, WHQL, Windows 8, Windows 7, BSMI, Green Mark, PSB, C-tick, MEPS, CLC, Energy Star 6.0, EPEAT Sliver |
| Wall Mount |
|
VESA® 100x100 mm |
| Package Contents |
|
LCD Display/ Power Cable /VGA cable/Quick Start Guide |
